제품 상세 정보:
|
|
| 원래 장소: | 중국 심천 |
|---|---|
| 브랜드 이름: | TOP-KING |
| 인증: | ISO9001:2008;RoHS |
| 모델 번호: | CHT-CBL-400S |
|
결제 및 배송 조건:
|
|
| 최소 주문 수량: | 5 채널 |
| 가격: | 협상 가능 |
| 포장 세부 사항: | 내부의 필름, 10 pcs 1 번의 묶음, 직조 가방에 포장. |
| 배달 시간: | 15-20 일로 일하 저장고 (양에 따른 실세)을 받았습니다 |
| 지불 조건: | 티/티 |
| 공급 능력: | 하루 1000 채널 |
|
상세 정보 |
|||
| PCB 크기 (L*W): | 80x50-510x350mm | PCB 방향: | LR/RL |
|---|---|---|---|
| PCB 높이: | 900±20mm | 공급합니다: | 4-6kgf/cm² |
| 무게: | 245KG | 경계 치수 (L%22W%22H): | 600x950x1860mm |
제품 설명
SMT SERIES PCB CONVEYOR MACHINE/ Cache The Cache Machine
Features
HMI operation system interface control operation, function switching which are simple and easy to understand
PLC control system, muliple electrical circut protection design which are security and stability
There are 30 pitches available for temporary storage
Integrate multiple functions, first-in, first-out, advanced-last-out, and direct-through
Servo positioning system, high positioning accuracy, fast lifting speed, high production efficiency,and large amount of storage
Standard SMEMA.sicnal communication
Technical Parameters
| Description | Can be used to buffer between SMT machines/Can be used to automatically collect AOl inspection NO/OK circuit boards to differend bins |
| Board capacity | 30pcs or specified by customer |
| Maximum load | 1.5kg/PCB |
| Cycle time |
About 12 Seconds |
| Step selection | 20,40mm or specified by customer |
| Power supply and electric load | 220V(AC,SP)850VA max |
| Board thickness | Min,0.6mm |
specification parameter
| Ten name of the | CHT350 | CHT-460 | |
| PCB Size(L*W) | 80x50-510x350mm |
80x50-510x460mm |
|
| Weight | 245Kg | 265Kg | |
| Boundary dimension (L*W*H) |
600x950x1860mm |
600x1060x1860mm | |
Our Company:
Shenzhen Jingji Technology Co., Ltd. Is a professional manufactuer for design, production and sale of industrial storage equipment, flexible production equipment, automation equipment and other kinds of instruments and gauges. beside, the company distributes anti-static peripherals.
We provide a comprehensive logistics plan in order to avoid waste of resources in course of purchase and supply chain by manufactures. It is our ultimate goal to provide all customers with full service, to meet exact demands of customers. To improve product quality, and to enhance customer satisfaction storage annd logistics as in automation industy.
